LINEA TEGULAR PLANK - Ceiling Tiles

LINEA Tegular Plank-Ceiling Tiles are a simple to install alternative to our traditional LINEA Plank products. These ceiling tiles are manufactured in standard sizes (2×2, 2×4,2×6, 2×8) and designed to lay into most standard 15/16” T–bar suspension systems. LINEA Plank Ceiling Tiles are available in a wide variety of solid wood species and finishing options for design flexibility. When combined with acoustical insulation, LINEA Tegular Plank ceiling tiles can achieve high acoustic performance

SPECIFICATION–example

Type:  LINEA Tegular Plank Ceiling Tiles
Wood Species: Download Chart
Slat Size: 1/2” x 1-1/2”
Finishes:  Natural Clear, Custom Stained or Tinted Clea Finishes in Matte, Satin or Semi–Gloss Sheen
Cross Members: 1/2” x 1-1/4” Plywood painted Black
Fabric/Scrim: Optional Standard Black, Class A Fire Rated.
Fire Rating : Class A per ASTM E–84 (USA) and CAN/ULC S102 (Canada)

PHYSICAL DATA

ACOUSTICS: LINEA Tegular Plank Ceiling Tiles without additional acoustic insulation, will act as a sound diffusor and should be considered acoustically transparent. When paired with acoustical insulation or duct liner behind, the panels can achieve high sound absorption.
FIRE RATING: Solid Wood FX Lumberguard or FX Lumberguard XT chemical fire retardants are factory applied to all LINEA Grille wood slats prior tofurther finishing to achieve a Class A Fire Rating when tested to ASTM E-84 (USA) and CAN/ULC S102 (Canada). When site cutting is required, FX Lumberguard can be re–applied to the cut locations and re–sealed to bring the panel back into conformance. Other topically applied chemical fire  retardants or intumescent finishes may be used in lieu of FX Lumberguard to achieve Class A Fire Rating. In some cases, the specifying consultant
may need to file an Alternate Solution with local authorities for approval. LINEA suggests consulting with local building code consultants during the specifying stage to avoid any potential issues related to Fire Rating.
SEISMIC: LINEA Grille panels are engineered for applications in all seismic areas when installed per LINEA installation instructions.
SITE CONDITIONS: Wood products are hygroscopic in nature and must be stored, installed & maintained in a controlled building environment. Temperature range should be maintained between 60° – 90° F (15° – 32°C). Relative Humidity range should be kept within a minimum 25% – max. 55% (not to exceed 20% RH from peaks to valleys). Failure to maintain site conditions will void the LINEA.
